Parsing semi-structured dataset in a relational database seems scary. Read on for how PostgreSQL® JSON functions allow your SQL queries to work with json and jsonb data.
Francesco Tisiot
|RSS FeedHead of Developer Experience at Aiven
Subscribe for the latest news and insights on open source, Aiven offerings, and more.
The original idea behind relational databases was "structure, then data": you needed to define what the data looked like before being able to insert any content. This strict data structure definition helped keeping datasets in order by verifying data types, referential integrity, and additional business conditions using dedicated constraints.
But sometimes life can't be predicted, and data can take different shapes. To enable some sort of flexibility, modern databases like PostgreSQL® started adding semistructured column options JSON, where only a formal check on the shape of the data is done.
PostgreSQL actually offers two options in this space, json and jsonb. The first one validates that the content is in JSON format and stores it as string, the second is a binary representation optimised for faster processing and better indexing. You can read more on Stack Overflow.
This blog post goes into detail about a few jsonb functions (with the json version being really similar without the b ending), by using a dataset containing restaurant information. Therefore, if you, like me, are always willing to discover new cuisines, take out your chef-investigator hat (a mix of Gordon Ramsay's and Sherlock Holmes's hat) and join me in the search for a good restaurant in our imaginary trip to India!
Let's start with the basics: we need a database with some sort of parsing capabilities for JSON data. PostgreSQL is perfect for that, and you can either use your own or create an instance in Aiven via the CLI:
Loading code...
The above creates an Aiven for PostgreSQL (--service-type pg) service called demo-pg , with the bare minimum hobbyist plan in the google-europe-west3 cloud region which is in Frankfurt, Germany. The service takes a couple of minutes to be ready; you can monitor that with the avn service wait command.
Any research starts with a dataset, and this is no different! There's a nice Zomato restaurants dataset available in Kaggle that can serve our purposes containing restaurant information for a lot of cities around the world.
All we need to download it is a valid Kaggle login. Once downloaded, we can unzip the archive file, and we'll get a folder containing 5 files (file1.json to file5.json). We can load them into our PostgreSQL service using the Aiven CLI, which will get the connection string and use the psql client:
Loading code...
Create a rest_reviews table containing a unique column called reviews_data of jsonb type
Loading code...
And then load the files with:
Loading code...
We are using sed -e ''s/\\/\\\\/g'' fileX.json to properly escape any \ characters, which are a problem in the \copy command (kudos to StackOverflow for the answer).
These files we just uploaded are nested JSON documents containing the Zomato API responses in an array like:
Loading code...
jsonb_array_elementsTo access the list of restaurants (in the restaurants field) we need to:
restaurants JSON item (this also removes the API limit exceeded errors)We can do that with the following SQL query:
Loading code...
In the above:
We use the jsonb_array_elements function to parse the jsonb array.
jsonb_array_elements(reviews_data) dt gives us dt, which is the outer array of API responses
-> retrieves a jsonb subitem. So
jsonb_array_elements(dt -> 'restaurants') restaurant gives us restaurant, which is the array contained in the restaurants field.restaurant -> 'restaurants' gives us the restaurant jsonb values from that array of restaurants.Like ->, ->> retrieves the jsonb subitem but this time as text. So 'restaurant' ->> 'name' retrieves the field name from the restaurant jsonb, as text.
When executing the above query we can see the data being parsed correctly
Loading code...
It would be nice to create a table having a row per restaurant, we can do that using a similar query.
Note: This step could do more and parse more columns, it's just an example of what's achievable.
Loading code...
We now have a table called restaurant_data with an integer field id and a jsonb field jsonb_data that we can use for further analysis.
Now we can start with our research. First let's explore some fields. Apart from the id and name, there's a nice location JSON subitem where we can find the restaurant city amongst other information.
Loading code...
In the above, check again the usage of -> to extract the jsonb subitem versus ->> to extract the same as text. The results are the following:
Loading code...
@>Let's talk money! What are the most expensive restaurants based on average_cost_for_two in Rs., (Indian Rupies) the local currency in India?
Loading code...
We use int again to say the price is an integer, and the @> operator to check that the jsonb_data JSON document contains {"currency": "Rs."}. An alternative would be to extract the currency subitem and filter with jsonb_data ->> 'currency' = 'Rs.'. The following are the results:
Loading code...
with_bucketOk, the above query gave me an idea of the cost, what about the quality? Let's explore the user_rating item and create a histogram with:
Loading code...
The above query uses the with_bucket function to assign the user_rating value to one of 10 buckets, each covering 0.5 in ratings (e.g. 0-0.5, 0.5-1) etc. The result below shows that we can safely filter for rating >= 4 and still retain a good choice of restaurants.
Loading code...
Should we try to minimise the spend? Let's search if there is any restaurant with a rating greater or equal than 4 and an average_cost_for_two less than 1000 Indian Rupees. Again, we are casting both aggregate_rating and average_cost_for_two to integers before applying the filter.
Loading code...
This shows quite a good selection of not too expensive but still good restaurants!
Loading code...
jsonb_array_length and jsonb_array_elementsLet's refine our research, are any of the resulting restaurants doing events? Checking events done in the past might give us some more insights on what the restaurant can offer. Since the item zomato_events contains an array of events, we can check for restaurants with at least 2 entries in that array, so we can get a sense of what's available.
Loading code...
To filter on zomato_events, we're using the jsonb_array_length function, which returns the number of items in a specific jsonb array. Interestingly we only get 3 rows.
Loading code...
Now that we have that list of three restaurants, let's have a look at what events they created to make our final decision
Loading code...
Wow, #FlauntYourPizza Contest seems interesting (and possibly very dangerous
Loading code...
Looks like we found our restaurant! Now it's time to go there, check the menu, and eat!
"Relational databases are too rigid", how many times did we hear that? It turns out they can also perform really well with semi structured data like JSON, and PostgreSQL in particular has a deep set of functions for manipulating JSON objects. So, next time you have a JSON dataset, maybe give PostgreSQL a try?
Some more resources that you might find useful:
avn service create demo-pg \
--service-type pg \
--plan hobbyist \
--cloud google-europe-west3avn service cli demo-pgcreate table rest_reviews (reviews_data JSONB);\copy rest_reviews from program 'sed -e ''s/\\/\\\\/g'' file1.json';
\copy rest_reviews from program 'sed -e ''s/\\/\\\\/g'' file2.json';
\copy rest_reviews from program 'sed -e ''s/\\/\\\\/g'' file3.json';
\copy rest_reviews from program 'sed -e ''s/\\/\\\\/g'' file4.json';
\copy rest_reviews from program 'sed -e ''s/\\/\\\\/g'' file5.json';[
{
"results_found": 17151,
"restaurants": [
{"restaurant": {"name":"Hauz Khas Social",...}},
{"restaurant": {"name":"Qubitos - The Terrace Cafe",...}},
...
},
{
"results_found": 100,
"restaurants": [
{"restaurant": {"name":"Spezia Bistro",...}},
{"restaurant": {"name":"Manhattan Brewery & Bar Exchange",...}},
...
},
...
{"message": "API limit exceeded", "code": 440, "status": ""}
{"message": "API limit exceeded", "code": 440, "status": ""}
]select restaurant -> 'restaurant' ->> 'name' restaurant_name
from rest_reviews
cross join lateral jsonb_array_elements(reviews_data) dt
cross join lateral jsonb_array_elements(dt -> 'restaurants') restaurant
limit 10; restaurant_name
----------------------------------
Hauz Khas Social
Qubitos - The Terrace Cafe
The Hudson Cafe
Summer House Cafe
38 Barracks
Spezia Bistro
Manhattan Brewery & Bar Exchange
The Wine Company
Farzi Cafe
Indian Grill Room
(10 rows)create table restaurant_data as
select
(restaurant -> 'restaurant' ->> 'id')::int id,
restaurant -> 'restaurant' jsonb_data
from rest_reviews
cross join lateral jsonb_array_elements(reviews_data) dt
cross join lateral jsonb_array_elements(dt -> 'restaurants') restaurant;select
jsonb_data ->> 'id' id,
jsonb_data ->> 'name' name,
jsonb_data -> 'location' ->> 'city' city
from restaurant_data limit 5; id | name | city
---------+----------------------------+-----------
308322 | Hauz Khas Social | New Delhi
18037817 | Qubitos - The Terrace Cafe | New Delhi
312345 | The Hudson Cafe | New Delhi
307490 | Summer House Cafe | New Delhi
18241537 | 38 Barracks | New Delhi
(5 rows)
select
jsonb_data ->> 'id' id,
jsonb_data ->> 'name' name,
(jsonb_data ->> 'average_cost_for_two')::int average_cost_for_two
from restaurant_data
where jsonb_data @> '{"currency": "Rs."}'
order by 3 desc
limit 5; id | name | average_cost_for_two
--------+------------------------------------------------------+----------------------
3400072 | Dawat-e-Nawab - Radisson Blu | 3600
2300187 | Waterside - The Landmark Hotel | 3000
3400059 | Peshawri - ITC Mughal | 2500
102216 | Chao Chinese Bistro - Holiday Inn Jaipur City Centre | 2500
3400060 | Taj Bano - ITC Mughal | 2500
(5 rows)with agg_bucket as (
select
width_bucket((jsonb_data -> 'user_rating' ->> 'aggregate_rating')::numeric, 0, 5, 10) bucket,
count(*) nr_restaurants
from restaurant_data
where jsonb_data @> '{"currency": "Rs."}'
group by width_bucket((jsonb_data -> 'user_rating' ->> 'aggregate_rating')::numeric, 0, 5, 10)
)
select bucket,
numrange(bucket*0.5 -0.5, bucket*0.5) range,
nr_restaurants
from agg_bucket
order by 1;bucket | range | nr_restaurants
-------+-----------+----------------
5 | [2.0,2.5) | 2
6 | [2.5,3.0) | 1
7 | [3.0,3.5) | 88
8 | [3.5,4.0) | 266
9 | [4.0,4.5) | 287
10 | [4.5,5.0) | 76
(6 rows)select
jsonb_data ->> 'id' id,
jsonb_data ->> 'name' name,
(jsonb_data ->> 'average_cost_for_two')::int average_cost_for_two,
(jsonb_data -> 'user_rating' ->> 'aggregate_rating')::numeric aggregate_rating
from restaurant_data
where jsonb_data ->> 'currency' = 'Rs.'
and (jsonb_data ->> 'average_cost_for_two')::int < 1000
and (jsonb_data -> 'user_rating' ->> 'aggregate_rating')::numeric >= 4
order by 4 desc, 3 asc
limit 5; id | name | average_cost_for_two | aggregate_rating
--------+---------------------------+----------------------+------------------
3400346 | Sheroes Hangout | 0 | 4.9
2600109 | Sagar Gaire Fast Food | 250 | 4.9
800468 | Grandson of Tunday Kababi | 300 | 4.9
3001321 | CakeBee | 350 | 4.9
96776 | Conçu | 600 | 4.8
(5 rows)select
jsonb_data ->> 'id' id,
jsonb_data ->> 'name' name,
(jsonb_data ->> 'average_cost_for_two')::int average_cost_for_two,
(jsonb_data -> 'user_rating' ->> 'aggregate_rating')::numeric aggregate_rating,
jsonb_array_length(jsonb_data -> 'zomato_events') nr_events
from restaurant_data
where jsonb_data ->> 'currency' = 'Rs.'
and (jsonb_data ->> 'average_cost_for_two')::int < 1000
and (jsonb_data -> 'user_rating' ->> 'aggregate_rating')::numeric >= 4
and jsonb_array_length(jsonb_data -> 'zomato_events') > 1
order by 5 desc, 4 desc, 3 asc
limit 5; id | name | average_cost_for_two | aggregate_rating | nr_events
---------+----------------+----------------------+------------------+-----------
103019 | Mutual's | 650 | 4.2 | 3
113537 | Puffizza | 700 | 4.3 | 2
18413814 | Aangan Horizon | 900 | 4.0 | 2
(3 rows)select
jsonb_data ->> 'id' id,
jsonb_data ->> 'name' name,
(jsonb_data ->> 'average_cost_for_two')::int average_cost_for_two,
(jsonb_data -> 'user_rating' ->> 'aggregate_rating')::numeric aggregate_rating,
events -> 'event' ->> 'title' event_title
from restaurant_data
cross join lateral jsonb_array_elements(jsonb_data -> 'zomato_events') events
where jsonb_data ->> 'currency' = 'Rs.'
and (jsonb_data ->> 'average_cost_for_two')::int < 1000
and (jsonb_data -> 'user_rating' ->> 'aggregate_rating')::numeric >= 4
and jsonb_array_length(jsonb_data -> 'zomato_events') > 1
order by 1,2,5
limit 5; id | name | average_cost_for_two | aggregate_rating | event_title
-------+----------+----------------------+------------------+-----------------------------------
103019 | Mutual's | 650 | 4.2 | ABHI SOLANKI LIVE
103019 | Mutual's | 650 | 4.2 | FREEBIRDS
103019 | Mutual's | 650 | 4.2 | IPL SPECIAL OFF
113537 | Puffizza | 700 | 4.3 | Dim Light Dinner (Every Thursday)
113537 | Puffizza | 700 | 4.3 | #FlauntYourPizza Contest
(5 rows)
